Car Loading Ramps (3500x615x1535kg)

£1,440.00 £1,200.00
Built to Order
Ask A Question
Car Loading Ramps (3500x615x1535kg)


3500mm length, 615mm width and a profile height of 40mm . These ramps include a maximum capacity of 1535kg, ideally suited for access with a low load height. These ramps are made from aluminium, which makes them exceptionally thin and lightweight. These are an ideal solution for loading vehicles with low ground clearance onto steps or up kerbs/steep drives.

Capacity and price is for the PAIR.

Car Ramps FAQ's

  • Connection Options
  • Customisable
  • Easy to Fit
  • European Made
  • Not for Solid Wheels
  • One Year Warranty

At only 40mm thick the TRP40 Series is a super thin and lightweight aluminium ramp ideally suited for customers with a low load height. Perfect for loading cars with low ground clearance onto low steps or up kerbs/steep driveways.

  • These ramps are only available without edges
  • Four different connection options available, however the default connection is the rest on connection
  • Custom load heights available
  • All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement
  • Quotes for bespoke ramps can be supplied on request
  • Not suitable for solid wheels found on road surfacing machines - for this type of machinery please see the industrial ramps for steel tracks
  • Fully TÜV certified

For assistance in specifying or current pricing please call the team or email

TUV Certification Image

Usage guidelines and safety information for our full vehicle ramp range can be found here.

SKU TRP40615/35
Default Connection Rest On Connection
Capacity (kg) 1535
Height of Ramps Profile (mm) 55
Length (mm) 3500
Max Load Height (mm) 625
Weight per Ramp (kg) 44
Weight Per Pair (kg) 88
Width (mm) 615
One Year Warranty Yes
Connection Options Available Yes
Customisable Yes
Easy to Fit Yes
European Made Yes
Not Solid Wheels Yes
Capacity Wheelbase 500mm (kg) 1422
Capacity Wheelbase 750mm (kg) 1550
Capacity Wheelbase 1000mm (kg) 1706
External Width (mm) 615
