Aluminium Loading Ramps (2500x550x18000kg)

£1,938.00 £1,615.00
Built to Order
Ask A Question
Aluminium Loading Ramps (2500x550x18000kg)

550mm wide x 2500mm long, with a 200mm profile thickness. Featuring a maximum capacity of 18,000kg, this is one of our heaviest duty ramps and is ideal for use as an industrial plant ramp or heavy duty commercial ramp. Please note the minimum track width is 450mm. Custom built sizes are available on request. Price and capacity stated is for the PAIR.

Aluminium Ramps for Plant & Machinery FAQs

  • Connection Options
  • Customisable
  • Easy to Fit
  • European Made
  • Not for Solid Wheels
  • One Year Warranty

One of our two heaviest duty ramps from our standard range. The TRP200/25TRP Series core profile thickness is 200mm.
At 550mm these ramps are over half a metre wide and feature a capacity of up to 18,000kg and are ideal for use as industrial plant ramps and as heavy duty as commercial ramps.

On the TRP200T series the minimum width of tracks/wheels is 450mm.

  • These ramps are available both with and without edges
  • Four different connection options available, however the default connection is the rest on connection
  • Custom load heights available
  • Not suitable for solid wheels found on road surfacing machines - for this type of machinery please see the industrial ramps for steel tracks
  • Quotes for bespoke ramps can be supplied on request
  • All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement
  • Fully TÜV certified

TUV Certification Image

Useage Guidelines and Safety Information for these ramps can be found here

Default Connection Rest On Connection
Capacity (kg) 18000
Height of Ramps Profile (mm) 200
Length (mm) 2500
Max Load Height (mm) 750
Min. Load Height (mm) 600
Weight per Ramp (kg) 52.5
Weight Per Pair (kg) 105
Width (mm) 550
Minimum Track Width (mm) 400
One Year Warranty Yes
Connection Options Available Yes
Customisable Yes
Easy to Fit Yes
European Made Yes
Not Solid Wheels Yes
Capacity Wheelbase 1000mm (kg) 14,000
Capacity Wheelbase 1500mm (kg) 18,000
Capacity Wheelbase 2000mm (kg) 18,000
